C04GL-11524G-800W Transaxle For Travel Mobility Scooter
Key Features
High-Performance Motors
The heart of the C04GL-11524G-800W is its powerful motor options, tailored to meet various terrain and speed requirements:
11524G-800W-24V-2800r/min Motor: This motor offers a reliable 2800 revolutions per minute, providing a smooth and stable ride for everyday use on flat surfaces.
11524G-800W-24V-4150r/min Motor: For those who need a bit more speed, this motor delivers 4150 revolutions per minute, ensuring quick and efficient travel.
11524G-800W-36V-5000r/min Motor: For more challenging terrains or longer distances, this high-performance motor offers an impressive 5000 revolutions per minute, ensuring powerful acceleration and hill-climbing capabilities.
Versatile Speed Ratios
The C04GL-11524G-800W transaxle is equipped with adjustable speed ratios, allowing you to customize your scooter’s performance to suit your needs:
16:1 Ratio: Ideal for general travel, this ratio provides a balance of speed and torque, making it suitable for most surfaces.
25:1 Ratio: Perfect for inclines and rougher terrain, this ratio offers increased torque for better traction and control.
40:1 Ratio: For those who need maximum power, this high-torque ratio ensures the scooter can handle the most demanding conditions with ease.
Reliable Braking System
Safety is paramount, and the C04GL-11524G-800W transaxle is equipped with a robust braking system to ensure controlled stops:
6N.M/24V Brake: This powerful brake system ensures reliable stopping power for the 24V motor options, providing operators with the control they need to navigate through tight spaces and crowded areas with confidence.
6NM/36V Brake: For the 36V motor option, this brake system offers the same reliable stopping power, ensuring safety and control at higher speeds.
How does the 11524G-800W-36V-5000r/min motor compare to the other options?
The 11524G-800W-36V-5000r/min motor is the high-voltage option among the three motor variants offered for the C04GL-11524G-800W travel mobility scooter. Here’s how it compares to the other two options:
1. Speed
11524G-800W-24V-2800r/min Motor: This motor offers a balance of speed and torque, ideal for applications requiring consistent power delivery and moderate speed.
11524G-800W-24V-4150r/min Motor: For operations that demand higher speeds, this motor variant delivers increased RPM, ensuring quick response times and efficient transportation.
11524G-800W-36V-5000r/min Motor: The high-voltage option provides the highest speed, making it perfect for rapid material handling in time-sensitive environments.
With a speed of 5000 revolutions per minute, it is significantly faster than the other two options, which makes it suitable for users who prioritize speed in their mobility scooter.
2. Voltage
11524G-800W-24V-2800r/min Motor and 11524G-800W-24V-4150r/min Motor: Both of these motors operate at 24V, which is a standard voltage for many mobility scooters and provides a good balance between power and energy efficiency.
11524G-800W-36V-5000r/min Motor: Operating at 36V, this motor offers increased power, which can be beneficial for overcoming inclines or carrying heavier loads at higher speeds.
3. Torque and Power
All three motors share the same output power of 800W, which ensures consistent performance across the board. However, the torque may vary slightly due to differences in speed and voltage. The 36V motor, with its higher voltage, might deliver a slightly higher torque at the wheels, which can be advantageous for hill climbing and heavy-duty use.
4. Application Suitability
11524G-800W-24V-2800r/min Motor: Best for general use where moderate speed and power are required.
11524G-800W-24V-4150r/min Motor: Ideal for users who need a faster scooter for quick errands or those who value speed in their mobility solutions.
11524G-800W-36V-5000r/min Motor: Perfect for rapid material handling and time-sensitive environments, where high speed is crucial.
5. Efficiency and Durability
Designed with high-quality materials and components, the transaxle is built to last, reducing maintenance costs and ensuring that your mobility scooter remains operational for longer periods.
The 36V motor, due to its higher voltage, may offer improved efficiency at higher speeds, which could result in longer battery life.
In conclusion, the 11524G-800W-36V-5000r/min motor stands out with its high speed and power, making it the top choice for those who need a mobility scooter that can handle high-speed travel with ease. It’s particularly suitable for users who prioritize speed and performance in their mobility solutions.
