C04GT-8216S-250W Electric Transaxle
Key Features:
Motor Specification: 8216S-250W-24V-3000r/min
This powerful 250W motor operates at 24V and has a high-speed rating of 3000 revolutions per minute (r/min), ensuring quick and efficient operation.
Ratio Options:
The transaxle offers a range of speed reduction ratios to suit various applications:
16:1 for applications requiring high torque at lower speeds.
25:1 for a balance of speed and torque, suitable for medium-duty applications.
40:1 for maximum torque output, ideal for heavy-duty operations where slow and steady movement is crucial.
Braking System:
Equipped with a 4N.M/24V brake, the C04GT-8216S-250W provides reliable stopping power. This electromagnetic brake is designed for safety-critical applications where immediate halting is necessary.
Technical Specifications:
Model Number: C04GT-8216S-250W
Motor Type: PMDC Planetary Gear Motor
Voltage: 24V
Power: 250W
Speed: 3000r/min
Available Ratios: 16:1, 25:1, 40:1
Brake Type: Electromagnetic Brake
Brake Torque: 4N.M
Mounting Type: Square
Application: Suitable for electric tugs,cleaning machine, and other electric vehicles requiring variable speed control and high torque output.
Advantages:
Compact Design: The compact design of the C04GT-8216S-250W allows for easy integration into various electric tug designs, saving space and reducing overall vehicle weight.
Versatile Speed Reduction Ratios: The multiple ratio options enable the transaxle to be tailored to specific operational requirements, enhancing performance and efficiency.
Reliable Braking: The 4N.M/24V brake ensures that the electric tug can come to a safe and immediate stop, reducing the risk of accidents in busy industrial environments.
