C05BQ-AC1.5KW Transaxle For Floor Grinding Polishing Machine
Product Detail
1Motor: AC1.5KW-24V-2800/5000r/min;
AC1.5KW-36V-2800/5000r/min;
AC1.5KW-48V-2800/5000r/min;
2Ratio: 25:1, 40:1.
3Brake: 12N.M+160 hydraulic drum brake.
1. Versatile motor options:
C05BQ-AC1.5KW Transaxle offers a variety of motor options to meet different voltage requirements:
AC1.5KW-24V-2800/5000r/min
AC1.5KW-36V-2800/5000r/min
AC1.5KW-48V-2800/5000r/min
These motor options ensure that the drive shaft is compatible with a variety of floor grinding and polishing machines, providing flexibility and a wide range of applications.
2. High-efficiency reduction ratio:
C05BQ-AC1.5KW Transaxle offers two reduction ratio options to suit different application requirements:
25:1
40:1
These reduction ratio options enable the drive shaft to provide high torque output while maintaining a lower speed, which is ideal for grinding and polishing operations.
3. Powerful braking system:
The C05BQ-AC1.5KW Transaxle is equipped with a 12N.M electromagnetic brake and a 160 hydraulic drum brake. This combined braking system provides powerful braking force, ensuring that the machine can stop safely and quickly in any situation.
Product advantages:
a. High power output:
The 1.5KW motor provides powerful power output, allowing the C05BQ-AC1.5KW Transaxle to easily handle heavy-duty grinding and polishing tasks.
b. Voltage compatibility:
Supporting 24V, 36V and 48V motor options enables the C05BQ-AC1.5KW Transaxle to adapt to various voltage requirements, increasing its application flexibility in different equipment.
c. Customized reduction ratio:
The two reduction ratio options provided allow customers to choose the appropriate reduction ratio according to specific application requirements to achieve optimal performance.
d. Safety brake:
The combination of powerful electromagnetic brakes and hydraulic drum brakes provides additional safety protection, ensuring safety during operation.
e. Durability and Reliability: The C05BQ-AC1.5KW Transaxle is designed with durability and reliability in mind, enabling it to operate for long periods of time in harsh working environments without frequent maintenance.
